A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302
  • A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302
  • A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302
  • A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302
  • A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302

A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302

Place of Origin CHINA
Brand Name OEM/ODM
Certification ISO
Model Number SGCC, DX51D,Q195,Q235
Product Details
Appearance:
Spangle Or No Spangle
Thickness:
0.15-3MM
Color:
Silver
Standard:
AISI, ASTM, DIN, GB, JIS
Material:
SGCC, DX51D,Q195,Q235
Technology:
Hot Dipped
Type:
Steel Coil
Width:
600mm-1250mm
Coil Weight:
3-8MT/Coil Or As Your Request
Spangle:
Small / Big / Regular
High Light:

Hot Dipped Galvanized Steel Coil JIS G3302

,

Astm A653 Cold Rolled Galvanized Steel Coil Q195

,

ASTM A653 cold rolled galvanized steel coil

Payment & Shipping Terms
Minimum Order Quantity
1 tons
Price
negotiable based on the quantity
Packaging Details
Standard seaport packing or as the custom request
Delivery Time
within 10 days after received the advance
Payment Terms
T/T, Western Union, L/C
Supply Ability
1000 tons per month
Product Description

Minimum Spangle Galvanized Steel Coil Not Skin - Passed Chromed And Oiled


Different galvanizing process makes the situation of its surface is different, such as common sequins, big sequins, small sequins, zero sequins, and the surface of the phosphatizing treatment. Galvanized layer thick, anti-corrosion ability. So it's suitable for outdoor environments.
Galvanized steel coils are coated with zinc because rust will not attack the protective metal. The outermost layer is all zinc, but the successive layers are a mixture of zinc and iron, and the interior is pure steel. These multilayers give metals amazing corrosion resistance. Zinc also acts as a sacrificial layer to protect steel. If rust is on the surface of galvanized steel coil, zinc will corrode first. This allows zinc to be applied to the nicks or scratches to prevent rust

Technical Standard
EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
Steel Grade
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490, SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type
Coil/Sheet/Plate/Strip
Thickness
0.12-6.00mm, or customer's requirement
Width
600mm-1500mm, according to customer's requirement
Type of Coating
Hot Dipped Galvanized Steel(HDGI)
Zinc Coating
30-275g/m2
Surface Treatment
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality
Approved by SGS, ISO
ID
508mm/610mm
Coil Weight
3-20 metric ton per coil
Package
Water-proof paper is inner packing, galvanized steel or coated steel sheet is outer packing, side guard plate, then wrapped by seven steel belt. or according to customer's requirement
Export market
Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc


A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302 0

A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302 1

A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302 2

A653M Astm A653 Cold Rolled Galvanized Steel Coil Q195 Grade 50 JIS G3302 3
